Fatboy SPECS |
|
Frame |
 |
Specialized M4 Premium Aluminum, fully
butted w/ smooth welds, tapered headtube, post-mount disc
dropouts, 190mm rear hub spacing, replaceable alloy derailleur
hanger |
|
Fork |
 |
Specialized FACT carbon, full monocoque,
tapered steerer, 135mm hub spacing |
|
Rear Shocks |
 |
none |
|
Rims |
 |
Specialized Fatboy SL, alloy disc, single wall,
90mm wide, sleeve joint, hookless design, 32h |
|
Hubs |
 |
Specialized MTB Hi Lo disc, alloy, sealed
cartridge bearings, 135mm wide, QR, 32h |
|
Spokes |
 |
Stainless, 14g |
|
Tires |
 |
Specialized Ground Control Fat, 120TPI, folding
bead, 26x4.6 |
|
Pedals |
 |
Specialized |
|
Crank |
 |
Custom Samox, 2x10, alloy, 100mm CNC spindle,
w/ BB |
|
Chain |
 |
KMC X10L, 10-speed, reusable Missing Link |
|
Rear Cogs |
 |
Sunrace, 10-speed, 11-36 |
|
Bottom Bracket |
 |
Samox, PF30 |
|
Front Derailleur |
 |
SRAM X7, 2x10, low direct mount |
|
Rear Derailleur |
 |
SRAM X7 Type 2, 10-speed,
medium cage |
|
Shifters |
 |
SRAM S-Series, Grip Shift,
10-speed |
|
Handlebars |
 |
Specialized, low rise, double butted 6061 alloy,
9-degree backsweep, 5-degree upsweep, 15mm rise, 31.8mm |
|
Stem |
 |
Specialized, 3D forged alloy, 4-bolt, 6-degree
rise, anti-corrosion hardware |
|
Headset |
 |
1-1/8 upper, 1-1/2 lower, Campy style,
integrated sealed cartridge bearings, split crown race, 3.8mm
cone spacer |
|
Brakeset |
 |
Tektro Gemini, hydraulic disc |
|
Brakelevers |
 |
Tektro Gemini, hydraulic disc |
|
Saddle |
 |
Body Geometry mountain, steel rails, 143mm |
|
Seatpost |
 |
ROCK SHOX
Reverb |
|
Colors |
 |
Camouflage |
|
Sizes |
 |
L |
|
Weight |
 |
14,4 kg |
|
|
| |
|
